Street Light Pole 10m Steel tapered
Street Light Pole 10m Steel tapered
Product information "Street Light Pole 10m Steel tapered"
Tapered steel street-light mast, hot dip galvanised, 10 meter height.
Hot-dip galvanised, weather and corrosion resistant according to DIN EN ISO 1461.
Additionally painted in any RAL colour (powder-coated) at an extra charge.
Steel pole S235 according to DIN EN 40-4.
With door 85 x 400 mm.
For mounting a floodlight or street light.
Dimensions:
h1 Length: 10000 mm
h2 Ground: 1500 mm
Foundation depth: Approx. 1600 mm
Pole end spigot Ø: 76mm (special order 108mm)
d2 Base Ø : Approx. 200 mm
s Wall thickness: Approx. 3 mm
* These masts are offered in various designs. The dimensions may vary.
The masts are very bulky. Delivery can only be made by a special truck. The freight costs are therefore expensive. If you order several masts, delivery costs will only be charged once.
If you order the luminaires from us, GEO-Technik will pay part of the transport costs for you.
| Bauform: | konisch |
|---|---|
| Masthöhe: | 10m |
Login
Zubehörempfehlung
Side Arm 1m for Street Light Pole
Top Cap for Lighting Pole 76mm
Street Light Pole Junction Box 16²
