Energy-efficient solar pole-mounted luminaires - sustainable lighting solutions for all applications
Unterkategorien
LT-SOL-A2030
Just to fix on any round pole 60mm diameter.General specifications: Lighted area: aprx. 20 x 9m Distance from pole to pole: aprx. 12 - 20 meter Recommended pole height: 3m - 6m Ambient temperature: -10°C ~ +65°C Protection degree: IP65 Protection class: III Low safe voltage Approvals: CE, RoHS, WEEE Guarantee: 2 yearsAluminium alloy casing grey. Dimensions: 700 mm * 330mm * 45 mm Lamp specifications: LED power: 30W Light colour 4000K pure white (on request also 3000K warm white or 6000K daylight). No uv-radiation for reduced insects attraction LED efficiacy: > 150 lm/w Lamp efficiacy: > 140 lm/wLuminous flux: > 5100 lm Dimming lumens: > 500 lmCentral illumination: > 10 Lux (6m) Average illumination: > 6 Lux (6m) LED life time: 100000 hours Motion sensor: Day-Night sensor PIR motion sensorLighting angle: 120° wideDetecting distance: 7-15mSystem controler specifications: Microprocessor charge controler. Automatic lamp start at sunset and turn-off by dawn. Timer-dimmer: Full power at start-up, automatic dimming at late night, for more safety at low battery capacity. Temperature feeded battery charging for extended battery life.Overcharge and deep-discharge protection for the battery. Solar panel specifications: High efficient monocrystalline silicone (tempered glass encapsulated) Power: 100W Efficiency: aprx. 20% Battery specifications: Battery type: Lithium Iron Phosphate, LiFePo4 battery Capacity: 384 WH maintenance-free, longlife. For solar cycling charge operation Lifetime about 8 Years / 20°C Autarkic backup for 2 nights at fully charged batteries. At absolutely no sunshine. No standard parcel service shipping to foreign countries !This product contains batteries, wich can be shipped only by sea freight or special service.
* Preise inkl. MwSt. zzgl. Versandkosten
LT-SOL-A2030S
Just to fix on any round pole 60mm diameter.General specifications: Lighted area: aprx. 20 x 9m Distance from pole to pole: aprx. 12 - 20 meter Recommended pole height: 3m - 6m Ambient temperature: -10°C ~ +65°C Protection degree: IP65 Protection class: III SELV Low safe voltage Approvals: CE, RoHS, WEEE Guarantee: 2 yearsAluminium alloy casing grey. Dimensions: 700 mm * 330mm * 45 mm Lamp specifications: LED power: 30W Light colour 4000K pure white (on request also 3000K warm white or 6000K daylight). No uv-radiation for reduced insects attraction LED efficiacy: > 150 lm/w Lamp efficiacy: > 140 lm/wLuminous flux: > 5100 lm Dimming lumens: > 500 lmCentral illumination: > 10 Lux (6m) Average illumination: > 6 Lux (6m) LED life time: 100000 hours Motion sensor: Day-Night sensor PIR motion sensorLighting angle: 120° wideDetecting distance: 7-15mSystem controler specifications: Microprocessor charge controler. Automatic lamp start at sunset and turn-off by dawn. Timer-dimmer: Full power at start-up, automatic dimming at late night, for more safety at low battery capacity. Temperature feeded battery charging for extended battery life.Overcharge and deep-discharge protection for the battery. Solar panel specifications: High efficient monocrystalline silicone (tempered glass encapsulated) Power: 100W Efficiency: aprx. 20% Battery specifications: Battery type: Lithium Iron Phosphate, LiFePo4 battery Capacity: 384 WH maintenance-free, longlife. For solar cycling charge operation Lifetime about 8 Years / 20°C Autarkic backup for 2 nights at fully charged batteries. At absolutely no sunshine. No standard parcel service shipping to foreign countries !This product contains batteries, wich can be shipped only by sea freight or special service.
* Preise inkl. MwSt. zzgl. Versandkosten
LT-SOL-A2030Y
Robust photovoltaic street light with LED lamp. Environmentally friendly lighting using solar power - in winter, when there is little sun, the light automatically switches to mains power.For illuminating streets, yards, driveways, deliveries, access roads, waste collection points, car parks, building yards, recycling centres.Mounted on a round metal pole or with a wall bracket at an extra charge.All-In-Two luminaires represent a good compromise between compact design for normal lighting poles and reliability.The solar module can be rotated separately from the luminaire in the direction of the sun.The brightness is comparable to a 125W mercury vapour lamp or 70W sodium vapour lamp.In winter, we recommend switching down the intensity of the basic lighting to ensure sufficient recharging even in dark weather. The solar light is maintenance-free (only the solar module should be cleaned occasionally with water).with water).Just to fix on any round pole 60- 76mm diameter.General specifications: Lighted area: aprx. 20 x 9m Distance from pole to pole: aprx. 12 - 20 meter Recommended pole height: 3m - 6m Ambient temperature: -10°C ~ +65°C Protection degree: IP65 Protection class: III SELV Low safe voltage Approvals: CE, RoHS, WEEE Guarantee: 2 yearsAluminium alloy casing grey. Dimensions: 700 mm * 330mm * 45 mm Lamp specifications: LED power: 30W Light colour 4000K pure white (on request also 3000K warm white or 6000K daylight). No uv-radiation for reduced insects attraction LED efficiacy: > 145 lm/w Lamp efficiacy: > 140 lm/wLuminous flux: > 4500 lm Dimming lumens: > 500 lmCentral illumination: > 10 Lux (6m) Average illumination: > 6 Lux (6m) LED life time: 100000 hours System controler specifications: Microprocessor charge controler. Automatic lamp start at sunset and turn-off by dawn. Timer-dimmer: Full power at start-up, automatic dimming at late night, for more safety at low battery capacity. Temperature feeded battery charging for extended battery life.Overcharge and deep-discharge protection for the battery. Solar panel specifications: High efficient monocrystalline silicone (tempered glass encapsulated) Power: 100W Efficiency: aprx. 20% Battery specifications: Battery type: Lithium Iron Phosphate, LiFePo4 battery Capacity: 384 WH maintenance-free, longlife. For solar cycling charge operation Lifetime about 8 Years / 20°C Autarkic backup for 2 nights at fully charged batteries. At absolutely no sunshine. No standard parcel service shipping to foreign countries !This product contains batteries, wich can be shipped only by sea freight or special service.
* Preise inkl. MwSt. zzgl. Versandkosten
LT-SOL-AF1
Robust photovoltaic area lighting with LED lamp - no power supply required.High brightness - comparable to 100 watt halogen light.With a switch - the lighting is switched on as needed.The shutdown takes place automatically after 1 or 2 hours with an adjustable timer.So turning off will not be forgotten and the battery will not deep discharge.The LED floodlight is rotatable and pivotable.All functions are pre-programmed charge on the project and customer requirements from us, so that the lamp is ready for use immediately after construction.Solar module (without extension): monocrystalline silicon 40W with very high efficiency (tempered safety glass, hail-resistant), about 25 years of life expectancy.This high-quality module technology allows charging also on cloudy days.Pole and brackets are hot dip galvanized (on surcharge with a UV-resistant painting).The screws are made from stainless VA steel.Robust LED luminaire head of diecast aluminum with high protection (water and storm protected).The solar lamp is maintenance-free - (only the solar module should be cleaned occasionally with water).Technical specifications:LED Lamp: Power LED 10W ChipsetLED lifetime: about 40,000 hoursEnergy Class: A +++Luminous flux: > 1100 LmLight color: 4000K cool whiteIlluminated area: Ca. 8 x 5mMast height: 4 mAutonomous operating time in overcast weather (with fully charged battery): a) basic version: 6 hours b) with extension kit autumn: 9 hours c) with extension kit winter: 12 hoursFor adequate reliability in autumn or winter, we strongly recommend our expansion sets.Ambient temperature: -20 °C ~ + 50 °C (extension possible on request)Solar battery: Lithium-Eisenphosphat LiFePo4 12V, maintenance-free, long life. Life is about 10 years / 20°CTemperature-optimized battery-charge and trickle charge to protect the batteries.Overvoltage and deep discharge protection for the battery.Reverse polarity and short circuit protection.Protection lamp head: IP66Protection Light Control: IP67Protection class: III Safety extra low voltageApprovals: CE, RoHS, WEEESupplied flat pack with the following components:LED lamp head with pole mounting,High power solar battery,Solar module with stable, screw-pole mounting,Galvanized steel mast, height 4 meters + anch. section 600mm for concreting,Microprocessor control lights (located conveniently accessible behind a lockable door in the mast).Illustrated installation instructions in German or English.All components are pre-wired and ready for fast assembly.20 years availability guarantee for spare parts.The ready-lamp is delivered disassembled, complete with solar panel, mast, battery and lamp.
* Preise inkl. MwSt. zzgl. Versandkosten
LT-SOL-AF2
Robust photovoltaic area lighting with LED lamp - no power supply required.High brightness - comparable to 600 watt halogen light.With a switch - the lighting is switched on as needed.The shutdown takes place automatically after 1 or 2 hours with an adjustable timer.So turning off will not be forgotten and the battery will not deep discharge.The LED floodlight is rotatable and pivotable.All functions are pre-programmed charge on the project and customer requirements from us, so that the lamp is ready for use immediately after construction.Solar module (without extension): monocrystalline silicon 60W with very high efficiency (tempered safety glass, hail-resistant), about 25 years of life expectancy.This high-quality module technology allows charging also on cloudy days.Pole and brackets are hot dip galvanized (on surcharge with a UV-resistant painting).The screws are made from stainless VA steel.Robust LED luminaire head of diecast aluminum with high protection (water and storm protected).The solar lamp is maintenance-free - (only the solar module should be cleaned occasionally with water).Technical specifications:LED Lamp: Power LED 20W ChipsetLED lifetime: about 40,000 hoursEnergy Class: A +++Luminous flux: > 2200 LmLight color: 4000K cool whiteIlluminated area: Ca. 15 x 8mMast height: 4 mAutonomous operating time in overcast weather (with fully charged battery): a) basic version: 6 hours b) with extension kit autumn: 9 hours c) with extension kit winter: 12 hoursFor adequate reliability in autumn or winter, we strongly recommend our expansion sets.Ambient temperature: -20 °C ~ + 50 °C (extension possible on request)Solar battery: Lithium-Eisenphosphat LiFePo4 12V, maintenance-free, long life. Life is about 10 years / 20°CTemperature-optimized battery-charge and trickle charge to protect the batteries.Overvoltage and deep discharge protection for the battery.Reverse polarity and short circuit protection.Protection lamp head: IP66Protection Light Control: IP67Protection class: III Safety extra low voltageApprovals: CE, RoHS, WEEESupplied flat pack with the following components:LED lamp head with pole mounting,High power solar battery,Solar module with stable, screw-pole mounting,Galvanized steel mast, height 5 meters + anch. section 800mm for concreting,Microprocessor control lights (located conveniently accessible behind a lockable door in the mast).Robust battery ground mounting box made of ABS, watertight, walkable, dimensions 550 x 550 x 480mm.Illustrated installation instructions in German or English.All components are pre-wired and ready for fast assembly.20 years availability guarantee for spare parts.The ready-lamp is delivered disassembled, complete with solar panel, mast, battery and lamp.
* Preise inkl. MwSt. zzgl. Versandkosten
LT-SOL-AF4
Robust photovoltaic area lighting with LED lamp - no power supply required.High brightness - comparable to 600 watt halogen light.With a switch - the lighting is switched on as needed.The shutdown takes place automatically after 1 or 2 hours with an adjustable timer.So turning off will not be forgotten and the battery will not deep discharge.The LED floodlight is rotatable and pivotable.All functions are pre-programmed charge on the project and customer requirements from us, so that the lamp is ready for use immediately after construction.Solar module (without extension): monocrystalline silicon 120W with very high efficiency (tempered safety glass, hail-resistant), about 25 years of life expectancy.This high-quality module technology allows charging also on cloudy days.Pole and brackets are hot dip galvanized (on surcharge with a UV-resistant painting).The screws are made from stainless VA steel.Robust LED luminaire head of diecast aluminum with high protection (water and storm protected).The solar lamp is maintenance-free - (only the solar module should be cleaned occasionally with water).Technical specifications:LED Lamp: Power LED 70W ChipsetLED lifetime: about 40,000 hoursEnergy Class: BLuminous flux: > 6900 LmLight color: 4000K cool whiteIlluminated area: Ca. 25 x 10mMast height: 5 mAutonomous operating time in overcast weather (with fully charged battery): a) basic version: 8 hours b) with extension kit autumn: 12 hours c) with extension kit winter: 16 hoursFor adequate reliability in autumn or winter, we strongly recommend our expansion sets.Ambient temperature: -20 °C ~ + 50 °C (extension possible on request)Solar battery: Lead gel 12V, maintenance-free, long life. Life is about 10 years / 20°CTemperature-optimized battery-charge and trickle charge to protect the batteries.Overvoltage and deep discharge protection for the battery.Reverse polarity and short circuit protection.Protection lamp head: IP66Protection battery box: IP66Protection Light Control: IP67Protection class: III Safety extra low voltageApprovals: CE, RoHS, WEEESupplied flat pack with the following components:LED lamp head with pole mounting,High power solar battery,Solar module with stable, screw-pole mounting,Galvanized steel mast, height 5 meters + anch. section 800mm for concreting,Microprocessor control lights (located conveniently accessible behind a lockable door in the mast).Robust battery ground mounting box made of ABS, watertight, walkable, dimensions 550 x 550 x 480mm.Illustrated installation instructions in German or English.All components are pre-wired and ready for fast assembly.20 years availability guarantee for spare parts.The ready-lamp is delivered disassembled, complete with solar panel, mast, battery and lamp.
* Preise inkl. MwSt. zzgl. Versandkosten
LT-SOL-AF5
Robust photovoltaic area lighting with LED lamp - no power supply required.High brightness - comparable to 800 watt halogen light.With a switch - the lighting is switched on as needed.The shutdown takes place automatically after 1 or 2 hours with an adjustable timer.So turning off will not be forgotten and the battery will not deep discharge.The LED floodlight is rotatable and pivotable.All functions are pre-programmed charge on the project and customer requirements from us, so that the lamp is ready for use immediately after construction.Solar module (without extension): monocrystalline silicon 120W with very high efficiency (tempered safety glass, hail-resistant), about 25 years of life expectancy.This high-quality module technology allows charging also on cloudy days.Pole and brackets are hot dip galvanized (on surcharge with a UV-resistant painting).The screws are made from stainless VA steel.Robust LED luminaire head of diecast aluminum with high protection (water and storm protected).The solar lamp is maintenance-free - (only the solar module should be cleaned occasionally with water).General specifications: Lighted area: aprx. 20 x 30mDistance from pole to pole: aprx. 20 metersRecommended pole height: 7m - 8mAmbient temperature: -20°C ~ +55°CMax. direct sunshine temperature: 85° C / 176 F degreeProtection class: III SELVApprovals: CE, RoHS, WEEE20 years sparepart supply ability.Lamp specifications: LED Lamp: Power SMD Chipset PhilipsLED power: 80WLife time: 50000 hoursLight colour: 4000K neutral white (on request 5000K cold white or 3000K warm white).No uv-radiation for reduced insects attractionLED efficiacy: > 125 lm/wLamp efficiacy: > 100 lm/wLuminous flux: 8400 LmCentral illumination: > 39 Lux (8m)Average illumination: > 23 Lux (8m)Casing: Rigid aluminium die-cast. Seawater and thunderstorm-proofProtection degree: IP66Guarantee: 5 yearsMast height: 8 mAutonomous operating time in overcast weather (with fully charged battery): a) basic version: 11 hours b) with extension kit autumn: 15 hours c) with extension kit winter: 18 hoursFor adequate reliability in autumn or winter, we strongly recommend our expansion sets.Ambient temperature: -20 °C ~ + 50 °C (extension possible on request)Solar battery: Lithium iron phosphate LiFePo4 12V, maintenance-free, long life 10 years / 20°CTemperature-optimized battery-charge and trickle charge to protect the batteries.Overvoltage and deep discharge protection for the battery.Reverse polarity and short circuit protection.Protection Light Control: IP67Supplied flat pack with the following components:LED lamp head with pole mounting,High power solar battery,Solar module with stable, screw-pole mounting,Galvanized steel mast, height 8 meters + anch. section 800mm for concreting,Microprocessor light control (located conveniently accessible behind a lockable door in the mast).Illustrated installation instructions in German or English.All components are pre-wired and ready for fast assembly.20 years availability guarantee for spare parts.The ready-lamp is delivered disassembled, complete with solar panel, mast, battery and lamp.
* Preise inkl. MwSt. zzgl. Versandkosten
LT-SOL-AF50
Robust photovoltaic square lighting with LED lamp - no power connection required. High light intensity - the brightness is comparable to 2000 Watt halogen light.
The lighting is switched on as required with a switch. Switching off is automatic after 1 or 2 hours via an adjustable timer. This way, switching off is not forgotten and the battery is not deep-discharged. The galvanised steel mast and the entire construction are so robust that kicking is pointless. The LED floodlight can be rotated and swivelled.
All functions are pre-programmed by us free of charge according to project and customer specifications, so that the light is ready for operation immediately after assembly.
The solar light is maintenance-free - (only the solar module should be cleaned with water occasionally).
Technical specifications:
Illuminated area: Aprx. 25 x 20m
Ambient temperature: -20°C ~ +50°C (extension -35°C ~ +65°C possible on request)
Protection class: III safety extra-low voltage
Approval marks: CE, RoHS, WEEE
20-year availability guarantee for spare parts.
Protection class luminaire control:IP67
Luminaire head specification:
2 robust LED luminaire heads made of die-cast aluminium
The LED floodlights can be rotated and swiveled.
LED lamp: SMD chipset
LED power: 140W total
Energy efficiency class B
Light colour 4000K neutral white
No UV radiation for reduced insect attraction
LED efficiency: > 160 lm/w
Luminaire efficiency: > 145 lm/w
Luminous flux lumen: 20800 Lm
Central illuminance: > 28 Lux
LED life approx. 100,000 hours
Protection class: IP66 (water and storm protected).
Impact resistance: IK10
Warranty 5 years
Solar module (without extension):
Monocrystalline silicon 240W with very high efficiency (hardened protective glass, hailproof), approx. 25 years life expectancy.
This high-quality module technology also guarantees charging in overcast conditions.
All brackets and fixings are hot-dip galvanised (also available with a paint finish of your choice at an extra charge).
The screws are made of VA stainless steel.
Battery storage:
Battery: lead-gel 12V
maintenance-free, longlife, for solar cycle operation
Service life approx. 5 - 10 years / 20°C
Function even at low temperatures.
For sufficient operating safety in autumn or winter, we strongly recommend our extension sets.
Self-sufficient operating time in overcast weather (with fully charged battery):
a) basic version: 6 hours
b) with extension set autumn: 9 hours
c) with extension set winter: 12 hours
Temperature-optimised battery charging and trickle charging to protect the batteries.
Overvoltage and deep discharge protection for battery. Reverse polarity and short circuit protection.
Mast:
Material: Steel pole, hot-dip galvanised
Visible height: 8 m
Ground section: 130 cm for setting in concrete
(on request also 4m - 12m height)
For easier erection, we also offer installation sleeves into which the mast can be inserted.
Lockable mast door, for easy access to the control unit.
Battery box:
The batteries sit in the ground for protection against temperature fluctuations (longer life).
Sturdy plastic box IP67 ( not walk-in version) with cable protection hose: Dimensions: L 496 x W 280 x H 270mm
On request ABS box IP66 (walk-in version): Dimensions: L 550 x W 550 x H 480mm
Delivery disassembled with the following components:
Galvanised steel pole,
2 x LED lamp head with pole mounting,
Solar module with stable, screwable pole mount,
Microprocessor luminaire control unit (easily accessible behind a lockable door in the pole).
Energy storage with floor installation box,
Illustrated assembly instructions in German or English. Other languages on request.
The ready-to-operate luminaire is delivered disassembled.
All components are pre-wired and prepared for quick assembly.
* Preise inkl. MwSt. zzgl. Versandkosten
LT-SOL-AF51
All functions are pre-programmed charge on the project and customer requirements from us, so that the lamp is ready for use immediately after construction.Solar module (without extension): Monocrystalline silicon 330W with very high efficiency (tempered safety glass, hail-resistant), about 25 years of life expectancy.This high-quality module technology allows charging also on cloudy days.All attachments and fasteners are galvanized or provided with a scratch-resistant and UV-resistant paint in a shade of gray.The screws are made from stainless VA steel.Robust LED luminaire head of diecast aluminum with high protection (water and storm protected).The solar lamp is maintenance-free - (only the solar module should be cleaned occasionally with water).Technical specifications:LED floodlight: SMD LED 140W ChipsetLED lifetime about 60,000 hoursEnergy Class BLuminous flux: > 15800 LmLight color 4000K cool whiteIlluminated area: Ca. 25 x 20mMast height: 6 mAutonomous operating time in overcast weather (with fully charged battery): a) basic version: 6 hours b) with extension kit autumn: 9 hours c) with extension kit winter: 12 hoursFor adequate reliability in autumn or winter, we strongly recommend our expansion sets.Ambient temperature: -20° C ~ + 50° C (extension possible on request)Solar battery: Lead gel 12V, maintenance-free, long life. Life is about 10 years / 20 ° CTemperature-optimized battery-charge and trickle charge to protect the batteries.Overvoltage and deep discharge protection for the battery.Reverse polarity and short circuit protection.Protection lamp head: IP66Protection battery box: IP66Protection Light Control: IP67Protection class: III Safety extra low voltageApprovals: CE, RoHS, WEEESupplied flat pack with the following components:LED lamp head with pole mounting,High power solar battery,Solar module with stable, screw-pole mounting,Galvanized steel mast, height 6 meters + anch. section 800mm for concreting,Microprocessor control lights (located conveniently accessible behind a lockable door in the mast).Robust battery ground mounting box made of ABS, watertight, walkable, dimensions 550 x 550 x 480mm.Illustrated assembly instructions in German or English. Other languages ??on request.All components are pre-wired and ready for fast assembly.20 years availability guarantee for spare parts.The ready-lamp is delivered disassembled, complete with solar panel, mast, battery and lamp.
* Preise inkl. MwSt. zzgl. Versandkosten
LT-SOL-AO12
Very easy and quick installation on existing masts.Solar panel, battery, lamp and controller are in one unit.No extra components are required.Recommended for sunny regions, like Africa, desert countries, South America, Philipines.High brightness corresponds to 100 watt halogen light.This solar light is maintenance free - only the solar panel should be cleaned occasionally with water.General specifications:Lighted area: aprx. 10 x 6mDistance from pole to pole: aprx. 10 meterRecommended pole height: 3m - 5mAmbient temperature: -10°C ~ +60°CProtection degree: IP65Protection class: III Low safe voltageApprovals: CE, RoHS, WEEE3 years guaranteePolycarbonate casing grey.Dimensions: 510 x 240 x 120mmLamp specifications:LED power: 12WLight colour 4000K pure white (on request also 3000K warm white or 6000K daylight).No uv-radiation for reduced insects attractionLED efficiacy: > 110 lm/wLamp efficiacy: > 100 lm/wLuminous flux: > 1200 lmCentral illumination: > 10 Lux (4m)Average illumination: > 6 Lux (4m)Life time: 60000 hoursMotion sensor:Day-Night sensorPIR motion sensorLighting angle: 120 deg (very wide)Detecting distance: 6mSystem controler specifications:Microprocessor charge controler.Automatic lamp start at sunset and turn-off by dawn. (Level adjustable)Timer-dimmer: Full power at start-up, automatic dimming at late night and full power again in the early morning, for more safety at low battery capacity.Temperature feeded battery charging for extended battery life.Overcharge and deep-discharge protection for the battery.Solar panel specifications: High efficient monocrystalline silicone(tempered glass encapsulated)Efficiency: aprx. 20%Power: 12WBattery specifications:Battery type: Lithium Iron Phosphate, LiFePo4 batterymaintenance-free, longlife, for solar cycling charge operationLifetime: about 8 Years / 20°CAutarkic backup: 2 nights at fully charged batteries. At absolutely no sunshine.Complete unit:Just to fix on any pole 60 - 90mm diameter.No standard parcel service shipping to foreign countries !This product contains batteries, wich can be shipped only by sea freight or special service.
* Preise inkl. MwSt. zzgl. Versandkosten
LT-SOL-AO15
Brightness is adjustable, with or without basic lighting, as well as time programmes. Easy to mount on straight steel poles or poles with side bracket or on a wall. Recommended for car park, private road, delivery, rubbish collection area, garages, yard ... The brightness is comparable to a 100W halogen lamp. All-In-One luminaires are not suitable for continuous operation, because otherwise the solar module does not provide enough energy in winter.The solar light is maintenance-free - (only the solar module should be cleaned with water occasionally).General technical data:Illuminated area: Approx. 10 x 6m Recommended pole spacing: Approx. 10 metres Mounting: On a building wall or sideways on a pole with 50-60mm diameter. Recommended mounting height: 3 - 5m Ambient temperature: -10°C ~ +60°C Protection class: III safety extra-low voltage Approval marks: CE, RoHS, WEEE Dimensions: 495 x 200 x 60mm LED Specification: Shapely LED lamp head made of aluminium LED lamp: SMD chipset LED power: 12W Light colour: 4000K neutral white (from 50 pcs. also 3000K warm white can be ordered). No UV radiation for reduced insect attraction LED efficiency: > 110 lm/w Luminaire efficiency: > 100 lm/w Luminous flux lumen: 1200 lm Central illuminance: >10 Lux (4m height) Average luminous intensity: > 6 Lux (4m) LED life approx. 60,000 hours Protection class: IP65 (water and storm protected). Warranty: 2 years Motion sensor:Twilight switch for automatic switch-on in darkness PIR motion detectorDetection angle: 120 deg Detection distance: 6m Luminaire control: Automatic switch-on at sunset and switch-off at sunrise. With motion detector to increase brightness to 100% for a short time. Duration of full illumination: 1 min. - then back to reduced mode. 3 selectable operating modes by pressing the on/off button several times:Summer mode: 3W dimmed lighting throughout the night - 12W if person is detected. Autumn mode: 3W dimmed lighting for the first 6 hours - With person detection 12W. and from midnight onwards 1.5W dimmed lighting - With person detection 6W. Winter mode: no lighting - only on person detection to 12W.Solar panel specifications: Monocrystalline silicon Hardened protective glass Efficiency: > 20% Power: 12Wp Life expectancy: approx. 20 years Battery storage: High-performance solar lithium-ion iron battery LiFePo4. Battery voltage: 11V maintenance-free, longlife. For solar cycle operation Service life approx. 10 years / 20°C Self-sufficient operating time: 210 switch-ons, 1 minute each (3.5 hours) in overcast weather with fully charged battery Temperature-optimised battery charging and trickle charging to protect the batteries. Overvoltage and deep discharge protection for battery. A suitable mast can be ordered separately.No standard parcel service shipping to foreign countries !This product contains batteries, wich can be shipped only by sea freight or special service.
* Preise inkl. MwSt. zzgl. Versandkosten
LT-SOL-AO25
Very easy and quick installation on existing masts.Solar panel, battery, lamp and controller are in one unit.No extra components are required.Recommended for sunny regions, like Africa, desert countries, South America, Philipines.Lighting of parking lot, drive, waste collection area, yard, drive way.High brightness corresponds to 80 watt mercury light or 50 watt sodium light.This solar light is maintenance free - only the solar panel should be cleaned occasionally with water.Just to fix on any round pole 60mm diameter.General specifications:Lighted area: aprx. 20 x 9mDistance from pole to pole: aprx. 12 - 20 metersRecommended pole height: 3m - 6mAmbient temperature: -10°C ~ +65°CProtection degree: IP65Protection class: III Low safe voltageEnergy efficiency class: CApprovals: CE, RoHS, WEEEGuarantee: 2 yearsAluminium alloy casing silvergrey Dimensions: 700 mm * 330mm * 64 mmLamp specifications:LED power: 30WLight colour 4000K pure white (on request also 3000K warm white or 6000K daylight).No uv-radiation for reduced insects attractionLED efficiacy: > 120 lm/wLamp efficiacy: > 100 lm/wLuminous flux: > 3300 lmDimming lumens: > 500 lmCentral illumination: > 10 Lux (6m)Average illumination: > 6 Lux (6m)LED life time: 100000 hoursMotion sensor:Day-Night sensorPIR motion sensorLighting angle: 120° wideDetecting distance: 7-15mSystem controler specifications:Microprocessor charge controler.Automatic lamp start at sunset and turn-off by dawn.Timer-dimmer: Full power at start-up, automatic dimming at late night, for more safety at low battery capacity.Temperature feeded battery charging for extended battery life.Overcharge and deep-discharge protection for the battery.Remote control available for selecting different lighting and operating modes in summer or winter.Solar panel specifications: High efficient monocrystalline silicone(tempered glass encapsulated)Power: 50WEfficiency: aprx. 20%Battery specifications:Battery type: Lithium Iron Phosphate, LiFePo4 batteryCapacity: 300.2WHmaintenance-free, longlife.For solar cycling charge operationLifetime about 10 Years / 20°CAutarkic backup for 2 nights at fully charged batteries. At absolutely no sunshine.No standard parcel service shipping to foreign countries !This product contains batteries, wich can be shipped only by sea freight, truck or special service.
* Preise inkl. MwSt. zzgl. Versandkosten
LT-SOL-AO34
Very easy and quick installation on existing masts.Solar panel, battery, lamp and controller are in one unit. No extra components are required.Recommended for sunny regions, like Africa, desert countries, South America, Philipines.High brightness corresponds to 50 watt mercury light or 200 watt halogen light.This solar light is maintenance free - only the solar panel should be cleaned occasionally with water.General specifications:Lighted area: aprx. 10 x 10mDistance from pole to pole: aprx. 10 meterRecommended pole height: 3m - 5mAmbient temperature: -10°C ~ +55°CProtection degree: IP65Protection class: III Low safe voltageApprovals: CE, RoHS, WEEEGuarantee: 2 yearsAluminium alloy casing, grey Dimensions: 500 mm * 100 mmLamp specifications:LED power: 20WLight colour: 6000K bright white (from 20 pcs. also 3000K warm white or 4000K pure white).No uv-radiation for reduced insects attractionLED efficiacy: > 120 lm/wLamp efficiacy: > 100 lm/wLuminous flux: > 2200 lmDimming lumens: > 300 lmCentral illumination: > 10 Lux (4m)Average illumination: > 6 Lux (4m)Life time: 60000 hoursSystem controler specifications:Microprocessor charge controler.Automatic lamp start at sunset and turn-off by dawn.Timer-dimmer: Full power at start-up, automatic dimming at late night and full power again in the early morning, for more safety at low battery capacity.Temperature feeded battery charging for extended battery life.Overcharge and deep-discharge protection for the battery.Solar panel specifications:High efficient monocrystalline silicone (tempered glass encapsulated)Efficiency: aprx. 20%Power: 20WBattery specifications:Battery type: Lithium Iron Phosphate, LiFePo4 batteryCapacity: 100.3WHmaintenance-free, longlife,for solar cycling charge operationLifetime: about 8 Years / 20°CAutarkic backup for 8 hours at fully charged batteries. At absolutely no sunshine.Complete unit: Just to fix on any pole with 60mm diameter.No standard parcel service shipping to foreign countries !This product contains batteries, wich can be shipped only by sea freight or special service.
* Preise inkl. MwSt. zzgl. Versandkosten
LT-SOL-AO3M
Very easy and quick installation on existing masts.Solar panel, battery, lamp and controller are in one unit.No extra components are required.Recommended for sunny regions, like Africa, desert countries, South America, Philipines.Lighting of parking lot, drive, waste collection area, yard, drive way.High brightness corresponds to 80 watt mercury light or 50 watt sodium light.This solar light is maintenance free - only the solar panel should be cleaned occasionally with water.Just to fix on any round pole 60mm diameter.General specifications:Lighted area: aprx. 20 x 9mDistance from pole to pole: aprx. 12 - 20 metersRecommended pole height: 3m - 6mAmbient temperature: -10°C ~ +65°CProtection degree: IP65Protection class: III Low safe voltageEnergy efficiency class: CApprovals: CE, RoHS, WEEEGuarantee: 2 yearsAluminium alloy casing silvergrey Dimensions: 700 mm * 330mm * 64 mmLamp specifications:LED power: 30WLight colour 4000K pure white (on request also 3000K warm white or 6000K daylight).No uv-radiation for reduced insects attractionLED efficiacy: > 120 lm/wLamp efficiacy: > 100 lm/wLuminous flux: > 3300 lmDimming lumens: > 500 lmCentral illumination: > 10 Lux (6m)Average illumination: > 6 Lux (6m)LED life time: 100000 hoursMotion sensor:Day-Night sensorPIR motion sensorLighting angle: 120° wideDetecting distance: 7-15mSystem controler specifications:Microprocessor charge controler.Automatic lamp start at sunset and turn-off by dawn.Timer-dimmer: Full power at start-up, automatic dimming at late night, for more safety at low battery capacity.Temperature feeded battery charging for extended battery life.Overcharge and deep-discharge protection for the battery.Remote control available for selecting different lighting and operating modes in summer or winter.Solar panel specifications: High efficient monocrystalline silicone(tempered glass encapsulated)Power: 50WEfficiency: aprx. 20%Battery specifications:Battery type: Lithium Iron Phosphate, LiFePo4 batteryCapacity: 300.2WHmaintenance-free, longlife.For solar cycling charge operationLifetime about 10 Years / 20°CAutarkic backup for 2 nights at fully charged batteries. At absolutely no sunshine.No standard parcel service shipping to foreign countries !This product contains batteries, wich can be shipped only by sea freight, truck or special service.
* Preise inkl. MwSt. zzgl. Versandkosten
%
LT-SOL-AO3ME30
Betriebssicherheit:
Standard
Very easy and quick installation on existing masts. Solar panel, battery, lamp and controller are in one unit. No extra components are required. Recommended for sunny regions, like Africa, desert countries, South America, Philipines. Lighting of parking lot, drive, waste collection area, yard, drive way. High brightness corresponds to 80 watt mercury light or 50 watt sodium light. This solar light is maintenance free - only the solar panel should be cleaned occasionally with water. Just to fix on any round pole 60mm diameter.General specifications: Lighted area: aprx. 20 x 9m Distance from pole to pole: aprx. 12 - 20 meter Recommended pole height: 3m - 6m Ambient temperature: -10°C ~ +65°C Protection degree: IP65 Protection class: III Low safe voltage Energy efficiency class: C Approvals: CE, RoHS, WEEE Guarantee: 2 yearsAluminium alloy casing grey. Dimensions: 700 mm * 330mm * 45 mm Lamp specifications: LED power: 30W Light colour 4000K pure white (on request also 3000K warm white or 6000K daylight). No uv-radiation for reduced insects attraction LED efficiacy: > 120 lm/w Lamp efficiacy: > 110 lm/wLuminous flux: > 3300 lm Dimming lumens: > 500 lmCentral illumination: > 10 Lux (6m) Average illumination: > 6 Lux (6m) LED life time: 100000 hours Motion sensor: Day-Night sensor PIR motion sensorLighting angle: 120° wideDetecting distance: 7-15mSystem controler specifications: Microprocessor charge controler. Automatic lamp start at sunset and turn-off by dawn. Timer-dimmer: Full power at start-up, automatic dimming at late night, for more safety at low battery capacity. Temperature feeded battery charging for extended battery life.Overcharge and deep-discharge protection for the battery. Solar panel specifications: High efficient monocrystalline silicone (tempered glass encapsulated) Power: 50W Efficiency: aprx. 20% Battery specifications: Battery type: Lithium Iron Phosphate, LiFePo4 battery Capacity: 230.2WH maintenance-free, longlife. For solar cycling charge operation Lifetime about 8 Years / 20°C Autarkic backup for 2 nights at fully charged batteries. At absolutely no sunshine. No standard parcel service shipping to foreign countries !This product contains batteries, wich can be shipped only by sea freight or special service.
* Preise inkl. MwSt. zzgl. Versandkosten
LT-SOL-AP1
Solar spotlight with LED. Made in Germany.Easy self-assembly and environmentally friendly.Stable LED floodlight made of die-cast aluminium, swivelling and rotatable.Luminous flux 1950 Lm The luminous intensity corresponds to approx. 200W halogen light.Light range max. approx. 20mLight colour 4000 K neutral white Energy efficiency class B Ambient temperature: -20°C ~ +70°C (in direct sunlight)Protection class IP44, class II. Control system:Automatic switch-on in standby mode via the light sensor at dusk. Switching on of the spotlight via the PIR motion detector (10m range).The lighting time is adjustable from 10 sec. to 10 min.Overvoltage and deep discharge protection for battery.Daily lighting duration with fully charged battery: 400 switch-ons of 2 minutes each or 180 switch-ons of 5 minutes each. (Optionally available with double duration or for continuous operation).The luminaire control unit is conveniently located behind a lockable door in the pole.Energy storage:Maintenance-free, high-performance lithium iron phosphate battery, long-life type, Service life: 5 - 8 years.Solar panels:12V solar panel for independent operation.Protected from wind, dirt and snow.20W monocrystalline silicon (tempered protective glass, hail resistant).20-year life expectancy.High-quality solar cell technology ensures charging even on cloudy days.On dark days in winter, recharging is limited, thus shortening the lighting duration. Steel pole:Hot-dip galvanised, height 4 metres + ground piece 800mm for setting in concrete (Additional scratch-resistant powder coating or for mounting with base plate available at an extra charge).Vandalism-proof.Scope of delivery:Disassembled luminaire with pole for easy self-assembly.
* Preise inkl. MwSt. zzgl. Versandkosten
LT-SOL-AP
Self-sufficient solar car park lighting with LED lamp - no power connection required - no underground cables.Recommended for countries with average solar radiation, such as Europe, Ukraine, New Zealand.High luminous intensity thanks to state-of-the-art SMD LED in conjunction with electronic 12V-60V DC PWM driver.The brightness is comparable to an 80W mercury vapour lamp or 50W sodium vapour lamp.Intelligent microprocessor system control.Design, manufacture and quality management in Germany.Due to the radiation characteristics and design of the LT-SOL-AP44 luminaire heads, when installedthe regulations for the protection of the night sky, as well as the recommendations of therecommendations of the LAI from 2015 for immision protection are complied with. In addition, by lowering thethe basic lighting - when the motion detector is inactive - can also be used to protect insects at night.insects can also be achieved.All brackets and fixings are hot-dip galvanised (also available with a coating of your choice at an extra charge).The screws are made of VA stainless steel.The solar light is maintenance-free (only the solar module should be cleaned occasionally with water). General technical data: Illuminated area: Approx. 25 x 10mRecommended pole spacing: Approx. 25 metresAmbient temperature: -20°C ~ +50°C (extension -35°C ~ +65°C possible on request)Protection class: III safety extra-low voltageTest mark: CE, RoHS, WEEE20-year availability guarantee for spare parts.Luminaire head specification: Robust LED luminaire head made of die-cast aluminiumLED lamp: SMD Chipset PhilipsLED output: 36WLight colour: 3000K warm white No UV radiation for reduced insect attractionLED efficiency: > 160 lm/wLuminaire efficiency: > 145 lm/wLuminous flux lumen: 5000 LmCentral illuminance: > 36 lux (5m height)Average light intensity: > 18 lux (5m)LED service life approx. 100,000 hoursProtection class: IP65 (water and storm-proof).Warranty: 5 yearsLuminaire control:Smart microprocessor control with wireless programming option.Readout of the current operating status with storage of measurement data for all components from the last few days.Automatic switch-on at sunset and switch-off at sunrise. (Switching level adjustable) The light can be set to an output of 10-30% throughout the night (from dusk) or in 5 time blocks (1-15 hours).If a person comes within the detection range of the motion detector (approx. 15m, 360°), the LED lamp is switched to 50-100% output, depending on the setting for 1-10 minutes.Due to the long winter months, the sum of the time blocks together should be at least 15 hours. The LED is switched on by the set night light detection threshold (voltage drop on the PV module).The light is also switched off at sunrise by the set night light detection threshold (voltage build-up on the PV module, the time blocks are ended).Example 1: From dusk 4 hours with 10% ambient lighting, with motion detector contact 100%, rest of the night (approx. 10 hours) ambient lighting 0% and motion detector contact 70%Example 2: 4 hours 10% ambient lighting, 100% with motion detector contact, then 6 hours only with motion detector contact 50%, rest of the night again 4 hours 10% ambient lighting, 100% with motion detector contactExample 3: All night (15 hours) at 10%, 100% with motion detector contactThe charge controller is also equipped with a Smart Power function that enables automatic dimming at night depending on the battery charge level.If the battery voltage falls below 50%, the lamp is automatically dimmed to 50%; this process is descending until the deep discharge protection kicks in.This setting enables safe operation even on low-light days in winter.The charge controller settings are preset by us according to customer requirements.If you would like to change the settings, you will need the S-SOLS29-5 remote control.We will be happy to help you decide on the right pre-settings.All functions are pre-programmed by us free of charge, depending on the project and customer requirements, so that the light is ready for operation immediately after installation.Temperature-optimised battery charging and trickle charging to protect the batteries.Overvoltage and deep discharge protection for battery.Reverse polarity and short-circuit protection.Additional fuseProtection class: IP66Warranty: 5 yearsMotion detector:Microwave sensorDetection angle 360°Range up to 12m Solar module specifications:Monocrystalline silicon with very high efficiency Hardened protective glass, hail-resistantThis high-quality module technology guarantees charging even on overcast days. On dark days in winter, recharging is limited, which shortens the lighting time.Efficiency: 20%Output: 120WpLife expectancy: approx. 25 yearsPerformance guarantee * 20 years 80% / 10 years 90%Battery storage: High-performance solar lithium-ion iron battery LiFePo4Battery voltage: 12V maintenance-free, long-life.For solar cycle operationService life 6 - 12 years / 20°C Function even at low temperatures.Self-sufficient operating time in cloudy weather (with fully charged battery):Basic version: 4 days (44 hours)The battery is located in the mast, behind the lockable door.Mast: Steel mast, hot-dip galvanisedVisible height: 5 mGround section: 80 cm for setting in concrete (6m - 8m height on request)For easier erection, we also offer installation sleeves into which the pole can be inserted.Lockable mast door for easy access to the controls.Supplied disassembled with the following components: LED lamp head with pole attachmentSolar module with stable pole attachment,Steel pole, light control unit and battery already mounted in the poleIllustrated assembly instructions in German or English. Other languages on request.All components are pre-wired and prepared for quick assembly.The ready-to-use light is delivered disassembled for safe transport.* The warranty is void in the event of force, incorrect use or improper assembly.
* Preise inkl. MwSt. zzgl. Versandkosten
LT-SOL-AP42
Robuste Photovoltaik-Straßenleuchte mit LED Lampe und smartem Bewegungssensor- kein Stromanschluss erforderlich.
Empfohlen für Länder mit durchschnittlicher Sonneneinstrahlung, wie Europa, Ukraine, Neuseeland.
Hohe Lichtstärke durch modernste SMD LED in Verbindung mit elektronischem 12V-60V DC PWM Treiber.
Die Helligkeit ist vergleichbar mit zwei 40W Leuchtstoffröhren, bzw. 300W Halogenlicht.
Intelligente Mikroprozessor-Systemsteuerung.
Konstruktion, Herstellung und Qualitätsmanagement in Deutschland.
Die Solarleuchte ist wartungsfrei - lediglich das Solarmodul sollte gelegentlich mit Wasser gereinigt werden.
Alle Halterungen und Befestigungen sind feuerverzinkt (gegen Aufpreis auch mit Lackierung nach Wunsch).
Die Schrauben bestehen aus VA Edelstahl rostfrei.
Allgemeine technische Daten:
Beleuchtete Fläche: Ca. 20 x 25m
Empfohlener Mastabstand: ca. 20 - 30 Meter
Umgebungstemperatur: -20°C ~ +50°C (Erweiterung -35°C ~ +65°C auf Anfrage möglich)
Schutzklasse: III Schutzkleinspannung
Prüfzeichen: CE, RoHS, WEEE
20 Jahre Verfügbarkeitsgarantie für Ersatzteile.
Leuchtenkopf Spezifikation:
Robuster LED Leuchtenkopf aus Alu-Druckguss
LED Lampe: SMD Chipset
LED Leistung: 2x 25W
Lichtfarbe 3000K warmweiß
Keine UV-Strahlung für reduzierte Insekten Anlockung
LED Effizienz: > 145 lm/w
Leuchten Effizienz: > 130 lm/w
Lichtstrom Lumen: 5000 Lm
Zentrale Beleuchtungsstärke: > 18 Lux (5m Höhe)
LED Lebensdauer ca. 100.000 Stunden
Schutzart: IP65 (wasser- und sturmgeschützt).
Schlagfestigkeit: IK10
Gewährleistung 5 Jahre
Leuchtensteuerung:Smarte Mikroprozessor Steuerung mit drahtloser Programmier-Möglichkeit.Auslesen des aktuellen Betriebszustandes mit Speicherung der Messdaten aller Komponenten der letzten Tage.Automatische Einschaltung bei Sonnenuntergang und Abschaltung bei Sonnenaufgang. (Schaltpegel einstellbar)
Die Leuchte kann die ganze Nacht (ab Dämmerung) oder in 5 Zeitblocks (1-15Std) auf eine Leistung von Bsp.10-30% eingestellt werden.Sollte eine Person in den Erfassungsbereich des Bewegungsmelder kommen (ca. 15m, 360°) wird die LED Lampe auf 50-100% Leistung, je nach Einstellung 1-10min geschaltet.
Durch die langen Wintermonate sollte die Summe der Zeitblöcke zusammen mindestens 15 Stunden betragen. Die Einschaltung der LED beginnt durch die eingestellte Nachtlichterkennungsschwelle (Spannungsabfall am PV Modul).
Die Abschaltung der Leuchte bei Sonnenaufgang erfolgt ebenfalls durch die festgelegte Nachtlichterkennungsschwelle (Spannungsaufbau am PV Modul, die Zeitblöcke werden beendet).
Beispiel 1: Ab Dämmerung 4 Stunden mit 10% Grundbeleuchtung, bei Bewegungsmelderkontakt 100%, Rest der Nacht (ca.10Std) Grundbeleuchtung 0% und Bewegungsmelderkontakt 70%
Beispiel 2: 4 Std 10% Grundbeleuchtung, 100% bei Bewegungsmelderkontakt, danach 6 Std nur bei Bewegungsmelderkontakt 50%, Rest der Nacht wieder 4 Std 10% Grundbeleuchtung, 100% bei Bewegungsmelderkontakt
Beispiel 3: Die ganze Nacht (15Std) auf 10%, bei Bewegungsmelderkontakt 100%
Zusätzlich ist der Laderegler mit einer Smart Power Funktion ausgerüstet, die eine automatische Dimmung in der Nacht je nach Akkuladezustand ermöglicht.Wenn die Akkuspannung unter 50% fällt, wird die Lampe automatisch auf 50% gedimmt, dieser Prozess ist absteigend bis der Tiefenentladeschutz einsetzt.Diese Einstellung ermöglicht einen sicheren Betrieb auch an den lichtschwachen Tagen im Winter.
Die Ladereglereinstellungen werden von uns nach Kundenwunsch voreingestellt.Möchten Sie Einstellungen verändern, benötigen Sie die Fernbedienung S-SOLS29-5.Gerne helfen wir Ihnen bei der Entscheidung der richtigen Voreinstellungen.Alle Funktionen werden je nach Projekt und Kundenwunsch von uns kostenfrei vorprogrammiert, sodaß die Leuchte sofort nach Aufbau betriebsfertig ist.Temperatur-optimierte Batterie-Ladung und Erhaltungsladung zur Schonung der Batterien.Überspannungs- und Tiefentladeschutz für Batterie.Verpolungs-und Kurzschlußschutz.Zusätzliche SchmelzsicherungSchutzart: IP66Gewährleistung: 5 Jahre
Bewegungsmelder:
Sensor Mikrowellen
Erfassungswinkel 360°
Reichweite bis 10m
Solarmodul Spezifikationen:
Monokristallines Silizium mit sehr hohem Wirkungsgrad
gehärtetes Schutzglas, hagelfest
Diese hochwertige Modul-Technologie gewährleistet auch Ladung bei bedecktem Himmel. An dunklen Tagen im Winter ist die Nachladung eingeschränkt, die Leuchtdauer ist damit verkürzt.
Wirkungsgrad: > 20%
Leistung: 360 Wp
Lebenserwartung: ca. 25 Jahre
Leistungsgarantie * 20 Jahre 80% / 10 Jahre 90%
* ausgenommen bei mechanischer Einwirkung
Batterie Speicher:
Batterie: Lithium-Eisenphosphat LiFePo4 12V,
wartungsfrei, longlife, für Solar Zyklenbetrieb
Lebensdauer ca. 8 - 12 Jahre / 20°C
Funktion auch bei niedrigen Temperaturen.
Autarke Betriebsdauer bei bedecktem Wetter (mit voll geladenem Akku):
Winter: 80 Stunden (ca. 8 Tage)
Die Batterien befinden sich im Mast, hinter der verriegelbaren Tür.
Mast:
Stahlmast, feuerverzinkt,
Sichtbare Höhe: 5 m
Erdstück: 80 cm zum Einbetonieren
(auf Anfrage auch 4m - 6m Höhe)
Zum leichteren Aufstellen bieten wir auch Einbauhülsen an, in die der Mast eingesteckt werden kann.
Verschließbare Masttür, für den leichten Zugang zum Steuergerät.
Anlieferung zerlegt mit folgenden Komponenten:
LED Lampenkopf mit Mastbefestigung,
Solar Batterie,
Solarmodul mit stabiler Mastbefestigung,
Stahlmast,
Leuchtensteuerung (bereits im Leuchtenkopf montiert).
Bebilderte Aufbauanleitung in deutscher oder englischer Sprache.
Alle Komponenten sind vorverkabelt und vorbereitet für den schnellen Aufbau.
Die betriebsfertige Leuchte wird zerlegt geliefert, für den sicheren Transport.
* Preise inkl. MwSt. zzgl. Versandkosten
LT-SOL-RING
High quality solid and robust lamp for bike path, parking, hiking trail.Energy efficiency class A +++Light source Power LED.Brightness 600 lm = 60 watt incandescent light.Pleasant light color 4000K neutral white (no cold, blue light).Monocrystalline solar module with very high efficiency (tempered protective glass, hailproof), approx. 25 years life expectancy. The high-quality solar cell technology also ensures charging in cloudy skies.Maintenance-free high performance solar lead gel accumulator 12V, longlife type, life span: 5 - 8 years.Light Control:Automatic switch on at sunset and switch off at sunrise.Adjustable dimming during late night and full power in the morning to extend battery life.Operating time / duration (please specify when ordering)You have the option from dawn to choose 4 consecutive time blocks with 1-15 hours duration and different light intensity of 10-100%.Example 1: Night reduction with shutdown and morning lightFrom dusk 4 hours with 100%, then 2 hours with 50%, starting 3 hours off (0%) and again 5 hours with 100%Example 2: Night shutdown5 hours 100%, 4 hours 0%, 5 hours 100%Example 3: Reduced5 hours with 100%, then 15 hours (rest of the night) with 50%In addition, the charge controllers are equipped with a smart power function that allows automatic dimming at night depending on the battery charge level.If the battery voltage drops below 50%, the lamp is automatically dimmed to 50%, this process is decreasing until the deep discharge protection starts.This setting enables safe operation even on the faint days in winter.The charge controller settings are preset by us according to customer requirements.If you want to change the settings, you need the remote control S-SOLS29.We will gladly help you to decide on the right presettings.All functions are preprogrammed by us according to project and customer specification, so that the luminaire is ready for operation immediately after assembly.Self-sufficient operating time in overcast weather (with fully charged battery):Basic version 6 days (60 hours)The new emergency lighting function ensures the lighting even with low battery charge during very long periods of bad weather,but with reduced luminosity.For extended operational safety in autumn or winter we strongly recommend our extension sets.Lighting range Ø = mast spacing: approx. 18 meters / height: 300 cmAmbient temperature: -20 ° C ~ + 40 ° C (on request -70 ° ... + 85 ° C)Steel mast: galvanized, height 3 meters + ground piece 600mm for setting in concrete,(For additional charge additionally scratch-resistant powder-coated or for mounting with base plate).Resistance to Vandalism. With service door in the mast (special key required).Maintenance-free - (only the solar cells should be freed from snow or leaves if necessary).Degree of protection IP54, class II.Total height with luminaire head and solar module approx. 400cm.Order quantity from 4 pieces (custom-made, smaller quantities on request).Delivery: Completely ready to use, pre-assembled, but disassembled into 4 parts (transport). With assembly instructions.10 years availability guarantee for spare parts.
* Preise inkl. MwSt. zzgl. Versandkosten
LT-SOL-Z
Robust photovoltaic street light with LED lamp - no power connection required.
Recommended for countries with average solar radiation, such as Europe, southern Russia, New Zealand.
High luminous intensity thanks to state-of-the-art SMD LED in combination with an electronic 12V-60V DC PWM driver.
The brightness is comparable to an 80W mercury vapor lamp or 50W sodium vapor lamp.
Very long, maintenance-free luminaire operation due to special design features.
Microprocessor Control,
All brackets and fixings are hot-dip galvanized (with surcharge also with a coating as desired).
The screws are made of VA stainless steel.
Construction, production and quality management in Germany.
The solar light is maintenance-free - only the solar module should occasionally be cleaned with water.
General technical data:
Illuminated area: approx. 25 x 10m
Recommended mast spacing: approx. 25 meters
Ambient temperature: -20 ° C ~ + 50 ° C (extension -35 ° C ~ + 65 ° C possible on request)
Protection class: III Protective extra-low voltage
Test mark: CE, RoHS, WEEE
20-year availability guarantee for replacement parts.
Lamp specifications:
LED Lamp: SMD Chipset Philips
LED power: 30W
Light colour 4000K pure white (on request also 3000K warm white or 6000K daylight).
No uv-radiation for reduced insects attraction
LED efficiacy: > 160 lm/w
Lamp efficiacy: > 145 lm/w
Luminous flux: > 5000 lm
Central illumination: > 36 Lux (5m pole height)
Average illumination: > 19 Lux (5m)
Life time: 80000 hours
Casing: Rigid aluminium die-cast. Seawater and thunderstorm-proof.
Dimensions: 470mm x 230mm x 60mm
Arm length: 300mm (on request, we supply with max. 2 meter arm)
Protection degree: IP65
Guarantee: 5 years
Light Control:
Smart microprocessor control with infrared programming option.
Reading the current operating status with storage of the measurement data of all components of the last days.
Automatic switch on at sunset and switch off at sunrise. (Switching level adjustable)
Adjustable dimming during the late night and full power in the morning to extend the duration of the light in bad weather.
Operating time / duration (please specify when ordering)
You have the option from dawn to choose 4 consecutive time blocks with 1-15 hours duration and different light intensity of 10-100%.
Example 1 - Night reduction with shutdown and morning light:
From dusk 4 hours with 100%, then 2 hours with 50%, then 3 hours off (0%) and early in the morning 5 hours with 100%
Example 2 - night shutdown: 4 hours 100%, 4 hours midnight 0%, 5 hours 100%
Example 3 - 4 hours bright in the evening, then reduced to 50% for 4 hours, then 10 hours (rest of the night) to 50%
In addition, the charge controller is equipped with a Smart Power function, which allows automatic dimming at night depending on the battery charge level.
If the battery voltage drops below 50%, the lamp is automatically dimmed to 50%, this process is decreasing until the deep discharge protection starts.
This setting enables safe operation even on the faint days in winter.
The charge controller settings are preset by us according to customer requirements.
If you want to change the settings, you need the remote control S-SOLS29.
We will gladly help you to decide on the right presettings.
All functions are preprogrammed by us free of charge, depending on the project and customer request, so that the luminaire is ready for use immediately after installation.
Temperature-optimized battery charge and trickle charge to extend battery life.
Overvoltage and deep discharge protection for battery.
Reverse polarity and short circuit protection.
Additional fuse
Protection class: IP66
Warranty: 5 years
Solar module specifications:
Monocrystalline silicon with very high efficiency
tempered protective glass, hailproof
This high quality module technology also ensures charge in overcast skies. On dark days in winter, the recharging is limited, the light duration is thus reduced.
Efficiency: > 19%
Power: 330Wp (without extension)
Life expectancy: approx. 25 years
Performance Guarantee * 20 years 80% / 10 years 90%
* except in the case of mechanical impact
Battery storage:
Battery Type: Lithium Ion LiFePo4 12V,
maintenance-free, longlife, for solar cycle operation
Lifetime approx. 10 years / 20 ° C
Function even at low temperatures.
For sufficient reliability in autumn or winter, we strongly recommend our extension sets.
Self-sufficient operating time in overcast weather (with fully charged battery):
a) Basic version: 44 hours
b) with extension set autumn: 36 hours
c) with extension set winter: 48 hours
The new emergency lighting function ensures the lighting even with low battery charge during very long periods of bad weather,
but with reduced luminosity.
The batteries are located in the mast and are protected from strong sunlight.
Mast:
Steel mast, hot-dip galvanized,
Visible height: 5 m
Ground piece: 80 cm for setting in concrete
(on request also 6m - 8m height)
For easier installation, we also offer installation sleeves into which the mast can be inserted.
Lockable mast door for easy access to the controls.
Delivery disassembled with the following components:
LED lamp head with mast mounting,
Solar battery
Solar module with stable, screw-down mast mounting,
Steel pole,
Light control (already mounted in the mast).
Illustrated assembly instructions in German or English. Other languages on request.
All components are pre-wired and prepared for quick setup.
* Preise inkl. MwSt. zzgl. Versandkosten
LT-SOL-Z46-2
Robust photovoltaic street light with LED lamp - no power connection required.
Recommended for countries with average solar radiation, such as Europe, southern Russia, New Zealand.
High luminous intensity thanks to state-of-the-art SMD LED in combination with an electronic 12V-60V DC PWM driver.
The brightness is comparable to 2 pcs. 80W mercury vapor lamps or 100W sodium vapor lamp.
Very long, maintenance-free luminaire operation due to special design features.
Microprocessor Control,
All brackets and fixings are hot-dip galvanized (with surcharge also with a coating as desired).
The screws are made of VA stainless steel.
Construction, production and quality management in Germany.
The solar light is maintenance-free - only the solar module should occasionally be cleaned with water.
General technical data:
Illuminated area: approx. 25 x 10m
Recommended mast spacing: approx. 25 meters
Ambient temperature: -20 ° C ~ + 50 ° C (extension -35 ° C ~ + 65 ° C possible on request)
Protection class: III Protective extra-low voltage
Test mark: CE, RoHS, WEEE
20-year availability guarantee for replacement parts.
Lamp specifications:
LED Lamp: SMD Chipset Philips
LED power: 30W
Light colour 4000K pure white (on request also 3000K warm white or 6000K daylight).
No uv-radiation for reduced insects attraction
LED efficiacy: > 160 lm/w
Lamp efficiacy: > 145 lm/w
Luminous flux: > 5000 lm
Central illumination: > 22 Lux (6m pole height)
Average illumination: > 11 Lux (6m)
Life time: 80000 hours
Casing: Rigid aluminium die-cast. Seawater and thunderstorm-proof.
Dimensions: 470mm x 230mm x 60mm
Arm length: 300mm (on request, we supply with max. 2 meter arm)
Protection degree: IP65
Guarantee: 5 years
Light Control:
Smart microprocessor control with infrared programming option.
Reading the current operating status with storage of the measurement data of all components of the last days.
Automatic switch on at sunset and switch off at sunrise. (Switching level adjustable)
Adjustable dimming during the late night and full power in the morning to extend the duration of the light in bad weather.
Operating time / duration (please specify when ordering)
You have the option from dawn to choose 4 consecutive time blocks with 1-15 hours duration and different light intensity of 10-100%.
Example 1 - Night reduction with shutdown and morning light:
From dusk 4 hours with 100%, then 2 hours with 50%, then 3 hours off (0%) and early in the morning 5 hours with 100%
Example 2 - night shutdown: 4 hours 100%, 4 hours midnight 0%, 5 hours 100%
Example 3 - 4 hours bright in the evening, then reduced to 50% for 4 hours, then 10 hours (rest of the night) to 50%
In addition, the charge controller is equipped with a Smart Power function, which allows automatic dimming at night depending on the battery charge level.
If the battery voltage drops below 50%, the lamp is automatically dimmed to 50%, this process is decreasing until the deep discharge protection starts.
This setting enables safe operation even on the faint days in winter.
The charge controller settings are preset by us according to customer requirements.
If you want to change the settings, you need the remote control S-SOLS29.
We will gladly help you to decide on the right presettings.
All functions are preprogrammed by us free of charge, depending on the project and customer request, so that the luminaire is ready for use immediately after installation.
Temperature-optimized battery charge and trickle charge to extend battery life.
Overvoltage and deep discharge protection for battery.
Reverse polarity and short circuit protection.
Additional fuse
Protection class: IP66
Warranty: 5 years
Solar module specifications:
Monocrystalline silicon with very high efficiency
tempered protective glass, hailproof
This high quality module technology also ensures charge in overcast skies. On dark days in winter, the recharging is limited, the light duration is thus reduced.
Efficiency: > 19%
Power: 330Wp (without extension)
Life expectancy: approx. 25 years
Performance Guarantee * 20 years 80% / 10 years 90%
* except in the case of mechanical impact
Battery storage:
Battery Type: Lithium Ion LiFePo4 12V,
maintenance-free, longlife, for solar cycle operation
Lifetime approx. 10 years / 20 °C
Function even at low temperatures.
For sufficient reliability in autumn or winter, we strongly recommend our extension sets.
Self-sufficient operating time in overcast weather (with fully charged battery):
a) Basic version: 36 hours
b) with extension set autumn: 54 hours
c) with extension set winter: 72 hours
The new emergency lighting function ensures the lighting even with low battery charge during very long periods of bad weather,
but with reduced luminosity.
The batteries are located in the mast and are protected from strong sunlight.
Mast:
Steel mast, hot-dip galvanized,
Visible height: 5 m
Ground piece: 80 cm for setting in concrete
(on request also 6m - 8m height)
For easier installation, we also offer installation sleeves into which the mast can be inserted.
Lockable mast door for easy access to the controls.
Delivery disassembled with the following components:
LED lamp head with mast mounting,
Solar battery
Solar module with stable, screw-down mast mounting,
Steel pole,
Light control (already mounted in the mast).
Illustrated assembly instructions in German or English. Other languages on request.
All components are pre-wired and prepared for quick setup.
* Preise inkl. MwSt. zzgl. Versandkosten
LT-SOL07
Elegant design and stable construction - no power supply required - environmentally friendly.Uses: cycle path lighting, footpaths, parks, driveways, pedestrian areas, cycle paths etc.Easy self-assembly and environmentally friendly.General technical data:Light environment Ø approx. 15 metres / Height: 300 cmAmbient temperature: -20°C ~ +40°CProtection class IP54, class IIMaintenance-free - (only the solar module should be cleared of snow or leaves if necessary).10-year availability guarantee for spare parts (custom-made).Delivery: Completely ready for use, but disassembled into 3 parts. With assembly instructions.Intelligent control: Smart microprocessor control with wireless programming option.Automatic switch-on and switch-off at dusk.Adjustable midnight break (lights up only in the evening and morning if required).Overcharge protection, deep discharge protection and automatically temperature-adjusted characteristic curve to extend battery life.The luminaire control is conveniently accessible behind a lockable door in the pole.Luminaire globe:Acrylic sphere 300mm diameterEnergy efficiency class CLight source: SMD LEDLight intensity: 400 lumen (brightness corresponds to a 40W incandescent lamp)Light colour: 4000K pleasant neutral white (no cold, blue light)LED service life: 25,000 hoursThe LEDs can be replaced.Solar module:Monocrystalline silicon (hardened protective glass, hail-resistant).Power: 40WLife expectancy: approx. 25 yearsThe high-quality module technology ensures charging even on cloudy days.On dark days in winter, recharging is limited and the lighting duration is thus shortened.Battery store:Battery: Lithium iron phosphate LiFePo4 12V,maintenance-free, longlife, for solar cycle operationService life: approx. 8 - 10 years / 20°CFunction even at low or high temperatures.For sufficient operating safety in autumn or winter, we strongly recommend our extension sets.Autonomous operating time in overcast weather (with fully charged battery):a) basic version: 24 hours (approx. 2-3 days)b) with extension set winter: 40 hours (approx. 4 days)The new emergency lighting function ensures lighting even when the battery charge is low during very long periods of bad weather,but with reduced luminosity.The batteries are located in the mast, behind the lockable door.Mast:Steel mast: Galvanised (additional scratch-resistant powder-coated at extra cost).Height 300cmTop end Ø 60mmEarth piece 600mm for setting in concrete (or inserting into a sleeve)
* Preise inkl. MwSt. zzgl. Versandkosten
LT-SOL10-1
Bell light - elegant in design and safe to operate - no power connection required.Usage: Cycle path lighting, footpaths, car park, driveway, pedestrian zone, cycle paths etc.Energy efficiency class A+++Easy self-assembly and environmentally friendly.Light source: Bright SMD LED bulb - replaceable.Luminous flux: 600 lumenBrightness corresponds to a 60W incandescent lampLight colour: 4000K pleasant neutral white (no cold, blue light).LED service life: 50,000 hoursSolar panel:50W monocrystalline silicon (tempered protective glass, hail-resistant).approx. 25 years life expectancy.The high-quality module technology ensures charging even on cloudy days.On dark days in winter, recharging is limited, thus the lighting duration is shortened.Battery storage:Lithium iron phosphate LiFePo4 12V,maintenance-free, longlife, for solar cycle operationService life approx. 7 - 10 years / 20°CFunction even at low or high temperatures.Intelligent control:Automatic switch-on and switch-off at dusk.Adjustable midnight break (lights up only in the evening and morning if required).Overcharge protection, deep discharge protection and automatic temperature-adjusted characteristic curve to extend battery life.The luminaire control unit is conveniently located behind a lockable door in the pole.Smart Energy Management ensures longer luminaire life even when the battery is low.Steel poleHeight 400cm, Ø 60mm galvanised (optional additional scratch-resistant powder coating).For setting in concrete (optional for erection with base plate).Operating conditions:Daily operation in overcast weather: 30h / 2 - 3 days.Light environment = mast spacing: Ø 18 metresAmbient temperature: -25°C ~ +45°CProtection class IP44, class IIMaintenance-free - (only the solar cells should be cleared of snow or leaves if necessary).Included in the delivery:High performance battery and solar panel, as well as lamp post and bulb.Minimum order quantity: 2 pieces
* Preise inkl. MwSt. zzgl. Versandkosten
LT-SOL10-2
Bell light - elegant in design and safe to operate - no power connection required.Usage: Cycle path lighting, footpaths, car park, driveway, pedestrian zone, cycle paths etc.Energy efficiency class A+++Easy self-assembly and environmentally friendly.Light source: Two bright LED bulbs - replaceable.Luminous flux: 2 x 600 lumenBrightness corresponds to two 60W incandescent lampsLight colour: 4000K pleasant neutral white (no cold, blue light).LED service life: 50,000 hoursSolar panel:100W monocrystalline silicon (tempered protective glass, hail-resistant).approx. 25 years life expectancy.The high-quality module technology ensures charging even on cloudy days.On dark days in winter, recharging is limited, thus the lighting duration is shortened.Battery storage:Lithium iron phosphate LiFePo4 12V,maintenance-free, longlife, for solar cycle operationService life approx. 7 - 10 years / 20°CFunction even at low or high temperatures.Intelligent control:Automatic switch-on and switch-off at dusk.Adjustable midnight break (lights up only in the evening and morning if required).Overcharge protection, deep discharge protection and automatic temperature-adjusted characteristic curve to extend battery life.The luminaire control unit is conveniently located behind a lockable door in the pole.Smart Energy Management ensures longer luminaire life even when the battery is low.Steel poleHeight 400cm, Ø 60mm galvanised (optional additional scratch-resistant powder coating).For setting in concrete (optional for erection with base plate).Operating conditions:Daily operation in overcast weather: 30h / 2 - 3 days.Light environment = mast spacing: Ø 18 metresAmbient temperature: -25°C ~ +45°CProtection class IP44, class IIMaintenance-free - (only the solar cells should be cleared of snow or leaves if necessary).Included in the delivery:High performance battery and solar panel, as well as lamp post and bulb.Minimum order quantity: 2 pieces
* Preise inkl. MwSt. zzgl. Versandkosten
Innovative, environmentally friendly lighting systems with intelligent control for urban and rural applications
Our solar pole lights combine state-of-the-art solar technology with high-quality workmanship and flexible lighting control. Developed in Germany and manufactured in our own metalworking shop, they offer self-sufficient, energy-efficient lighting systems that cut electricity costs and reduce CO₂ emissions. Whether in public areas, residential complexes, industrial areas or remote locations - this is where sustainable innovation and individual lighting solutions come together.
Precision in solar technology and design
Thanks to the use of energy-saving solar panels and intelligent microprocessor controls, our pole-mounted luminaires guarantee maximum operational reliability and efficiency. Innovative sensor technology and flexible lighting control enable tailor-made solutions that are convincing in both urban centers and rural regions.
Energy saving and environmental awareness
Our self-sufficient lighting systems harness the power of solar energy to lower electricity consumption and reduce CO₂ emissions at the same time. Cost efficiency and low installation costs make these sustainable lighting solutions the ideal choice for public areas, industrial zones and locations that are difficult to access.
Varied application options and individual solutions
Thanks to variable control options - from motion detectors and timers to manual operation - our solar pole-mounted luminaires can be flexibly adapted to the needs of a wide range of applications. Whether parking lots, cycle paths and footpaths or sports and riding arenas, the focus here is on individual lighting innovation.
