Innovative Hybrid Solar Street Lighting – Reliable LED Solutions with Automatic Power Switching

Powerful and safe - no electrical grid required. Recommended for average sunshine regions, like Europe, southern Russia, New Zealand. High brightness corresponds to 40 watt fluorescent light. Very long maintenance-free system lifespan, by use of efficient LED lamps and electronic 24V-60V PWM driver. Microprocessor system control for lighting and charging. Pole and brackets are hot dip galvanized (on surcharge with a UV-resistant painting). The screws are made of stainless steel. This solar light is maintenance free - only the solar panel should be cleaned occasionally with water. Our systems are provided with serial numbers, wich can be validated to protect against malicious copies. General specifications: Lighted area: aprx. 18 x 8m Distance from pole to pole: 18 - 25 meters Ambient temperature: -20°C ~ +55°C (extended temperature range -35°C ~ +65°C available on request) Max. direct sunshine temperature: 85° C / 176 F degree Protection class: III Low safe voltage Approvals: CE, RoHS, WEEE 20 years sparepart supply ability. Lamp specifications: LED Lamp: SMD chipset LED power: 18W Energy efficiency class: A Light colour: 4000K neutral white (on request 5000K cold white or 3000K warm white). No uv-radiation for reduced insects attraction LED efficiency: > 160 lm/w Lamp efficiacy: > 140 lm/w Luminous flux: 2500 Lm Central illumination: > 8 Lux (at 5m pole height) Life time: Aprx. 100000 h Casing: Rigid aluminium die-cast. Seawater and thunderstorm-proof. Protection degree: IP66 5 years guarantee System controler specifications: Programmable smart processor charge controler. Wireless remote control Metering memory for actual and last days system status. Automatic lamp start at sunset and turn-off by dawn. (Level adjustable) Timer-dimmer: Full power at start-up, automatic dimming at late night and full power again in the early morning, for more safety at low battery capacity. All functions are pre-programmed by us, for the project and to customer specifications, so that the lamp is ready for operation immediately after installation. Temperature feeded battery charging for extended battery life. Overcharge and deep discharge protection for the battery. Reverse polarity and electronic short circuit protection. Additional electric fuse Protection degree : IP66 5 years guarantee Solar panel specifications: High efficient monocrystalline silicone (tempered glass encapsulated, hailproof) This modern cell technology has a high degree of efficiency and allows charging also at cloudy weather. Efficiency: > 16% Power: 100Wp Life expectancy: aprx. 25 years 20 years 80% power guaranty * 10 years 90% power guaranty * * excepted is the complete failing (3 years guarantee) Battery storage: High performance lithium iron phosphate accumulator LiFePo4 Battery voltage: 12V maintenance-free, longlife. For solar cycle operation Lifetime 6 - 10 years / 20°C Function even at low temperatures. For sufficient reliability in autumn or winter, we strongly recommend our extension sets. Autonomy time in overcast weather (with fully charged battery): a) Basic version: 40 hours (4 days) b) with extension set winter: 80 hours (8 days) The new emergency lighting function ensures lighting even during low battery charging during very long periods of bad weather, but with reduced luminosity. The battery is mounted inside the mast, behind the lockable door. Pole: Steel pole, hot-dip galvanized, Upper height 5 m inground length: 800mm Installation into concrete. With lockable service door, for easy acces to the controller. Including following components: LED light fixture with arm and pole mount bracket. LiFePo4 battery, Solar module with frame and bracket for adjustable top-mount. System controler. Steel pole. Manual for easy mechanical and electrical setup in english language. Other languages on request. Complete pre-wired unit

Powerful and robust.High brightness corresponds to 80 watt mercury light.Very long maintenance-free system lifespan, by use of efficient LED lamps and electronic 24V-60V PWM driver.Microprocessor system control for lighting and charging.All components are surfaced with a grey, scratchproof 2-layers UV-resistant coating.The screws are made of stainless steel.This solar light is maintenance free - only the solar panel should be cleaned occasionally with water.Our systems are provided with serial numbers, wich can be validated to protect against malicious copies.General specifications:  Lighted area: aprx. 27 x 24mDistance from pole to pole: 25 - 30 meterAmbient temperature: -20°C ~ +55°C (extended temperature range -35°C ~ +65°C available on request)Max. direct sunshine temperature: 85° C / 176 F degreeProtection class: III Low safe voltageApprovals:    CE, RoHS, WEEE20 years sparepart supply ability.Lamp specifications:LED Lamp:    SMD Chipset PhilipsLED power:   2x 30WLight colour 4000K pure white (on request also 3000K warm white or 6000K daylight).No uv-radiation for reduced insects attractionLED efficiacy: > 160 lm/wLamp efficiacy: > 145 lm/wLuminous flux: 2x > 5000 lmCentral illumination: > 22 Lux (6m pole height)Average illumination: > 12 Lux (6m)Life time:       100000 hoursCasing:           Rigid aluminium die-cast. Seawater and thunderstorm-proof.Dimensions:  470mm x 230mm x 60mmArm length:   300mm (on request, we supply with max. 2 meter arm)Protection degree: IP65Guarantee:    5 yearsSystem controler specifications:  Programmable Processor charge controler.Infra Red remote controlMetering memory for actual and last days system status.Automatic lamp start at sunset and turn-off by dawn. (Level adjustable)Timer-dimmer: Full power at start-up, automatic dimming at late night and full power again in the early morning, for more safety at low battery capacity.All functions are pre-programmed by us, for the project and to customer specifications, so that the lamp is ready for operation immediately after installation.Temperature feeded battery charging for extended battery life.Overcharge and deep-discharge protection for the battery.Reverse polarity and electronic short circuit protection.Additional electric fuseProtection degree: IP665 years guaranteeSolar panel specifications:High efficient monocrystalline silicone(tempered glass encapsulated, hailproof)This modern cell technology has a high degree of efficiency and allows charging also at cloudy weather.Efficiency:      > 20%Power:            335WpLife expectancy: aprx. 25 years20 years 80% power guaranty *10 years 90% power guaranty ** excepted is the complete failing (3 years guarantee)Battery specifications:Battery type: Lead gel 12VOn option Li-Ion LiFePo4 batterymaintenance-free, longlife.For solar cycling charge operationLifetime: about 10 Years / 20°CFunctions well, even under low temperature.Autonomy at no sunshine or dark-cloudy weather (with fully charged battery):a) Standard version: 4 days (40 h)b) with extension kit autumn: 5 days (60 h)c) with extension kit winter: 7 days (80 h)Battery box:The batteries are located underground for equalized temperature (longer life) and thieve protection.Rigid plastic box IP67 (non walkover) with cabel protection hose, steel reinforced:Size: L 496 x w 280 x h 270mmon option ABS plastic box IP66 (walk over):Size: L 550 x w 550 x h 480mmPole:Steel pole, hot-dip galvanized,Upper height 6 minground length: 800mmInstallation into concrete.With lockable service door, for easy acces to the controller.Including following components:LED light fixture with arm and pole mount bracket.Solar battery,Recessed battery box,Solar module with frame and bracket for adjustable top-mount.System controler.Steel pole.Manual for easy mechanical and electrical setup in english language. Other languages on request.

Powerful and robust - there is no electrical grid required. Recommended for average sunshine regions, like Europe, southern Russia, New Zealand. High brightness corresponds to 80 watt mercury light. Very long maintenance-free system lifespan, by use of efficient LED lamps and electronic 24V-60V PWM driver. Microprocessor system control for lighting and charging. All components are surfaced with a grey, scratchproof 2-layers UV-resistant coating. The screws are made of stainless steel. This solar light is maintenance free - only the solar panel should be cleaned occasionally with water. Our systems are provided with serial numbers, wich can be validated to protect against malicious copies. General specifications: Lighted area: aprx. 27 x 24m Distance from pole to pole: 25 - 30 meter Ambient temperature: -20°C ~ +55°C (extended temperature range -35°C ~ +65°C available on request) Max. direct sunshine temperature: 85° C / 176 F degree Protection class: III Low safe voltage Approvals: CE, RoHS, WEEE 20 years sparepart supply ability. Lamp specifications: LED Lamp: SMD Chipset Philips LED power: 2* 30W Light colour 4000K pure white (on request also 3000K warm white or 6000K daylight). No uv-radiation for reduced insects attraction LED efficiacy: > 160 lm/w Lamp efficiacy: > 145 lm/w Luminous flux: 2* > 5000 lm Central illumination: > 36 Lux (5m pole height) Average illumination: > 19 Lux (5m) Life time: 80000 hours Casing: Rigid aluminium die-cast. Seawater and thunderstorm-proof. Dimensions: 470mm x 230mm x 60mm Arm length: 300mm (on request, we supply with max. 2 meter arm) Protection degree: IP65 Guarantee: 5 years System controler specifications: Programmable Processor charge controler. Infra Red remote control Metering memory for actual and last days system status. Automatic lamp start at sunset and turn-off by dawn. (Level adjustable) Timer-dimmer: Full power at start-up, automatic dimming at late night and full power again in the early morning, for more safety at low battery capacity. All functions are pre-programmed by us, for the project and to customer specifications, so that the lamp is ready for operation immediately after installation. Temperature feeded battery charging for extended battery life. Overcharge and deep-discharge protection for the battery. Reverse polarity and electronic short circuit protection. Additional electric fuse Protection degree: IP66 5 years guarantee Solar panel specifications: High efficient monocrystalline silicone (tempered glass encapsulated, hailproof) This modern cell technology has a high degree of efficiency and allows charging also at cloudy weather. Efficiency: > 17% Power: 300Wp Life expectancy: aprx. 25 years 20 years 80% power guaranty * 10 years 90% power guaranty * * excepted is the complete failing (3 years guarantee) Battery specifications: Battery type: Lead gel 12V On option Li-Ion LiFePo4 battery maintenance-free, longlife. For solar cycling charge operation Lifetime: about 10 Years / 20°C Functions well, even under low temperature. Autonomy at no sunshine or dark-cloudy weather (with fully charged battery): a) Standard version: 4 days (40 h) b) with extension kit autumn: 5 days (60 h) c) with extension kit winter: 7 days (80 h) Battery box: The batteries are located underground for equalized temperature (longer life) and thieve protection. Rigid plastic box IP67 (non walkover) with cabel protection hose, steel reinforced: Size: L 496 x w 280 x h 270mm on option ABS plastic box IP66 (walk over): Size: L 550 x w 550 x h 480mm Pole: Steel pole, hot-dip galvanized, Upper height 6 m inground length: 800mm Installation into concrete. With lockable service door, for easy acces to the controller. Including following components: LED light fixture with arm and pole mount bracket. Solar battery, Recessed battery box, Solar module with frame and bracket for adjustable top-mount. System controler. Steel pole. Manual for easy mechanical and electrical setup in english language. Other languages on request.

Robust photovoltaic street light with LED lamp. High luminous intensity thanks to state-of-the-art SMD LED in combination with an electronic 12V-60V DC PWM driver. The brightness is comparable to an 80W mercury vapor lamp or 50W sodium vapor lamp. Very long, maintenance-free luminaire operation due to special design features. Microprocessor Control, All brackets and fixings are hot-dip galvanized (with surcharge also with a coating as desired). The screws are made of VA stainless steel. Construction, production and quality management in Germany. General technical data: Illuminated area: approx. 25 x 10m Recommended mast spacing: approx. 25 meters Ambient temperature: -20° C ~ + 50° C (extension -35° C ~ + 65° C possible on request) Protection class: III Protective extra-low voltage Test mark: CE, RoHS, WEEE 20-year availability guarantee for replacement parts. Lamp specifications: LED Lamp: SMD Chipset Philips LED power: 30W Light colour 4000K pure white (on request also 3000K warm white or 6000K daylight). No uv-radiation for reduced insects attraction LED efficiacy: > 160 lm/w Lamp efficiacy: > 145 lm/w Luminous flux: > 5000 lm Central illumination: > 36 Lux (5m pole height) Average illumination: > 19 Lux (5m) Life time: 80000 hours Casing: Rigid aluminium die-cast. Seawater and thunderstorm-proof. Dimensions: 470mm x 230mm x 60mm Arm length: 300mm (on request, we supply with max. 2 meter arm) Protection degree: IP65 Guarantee: 5 years Light Control: Smart microprocessor control with infrared programming option. Reading the current operating status with storage of the measurement data of all components of the last days. Automatic switch on at sunset and switch off at sunrise. (Switching level adjustable) Adjustable dimming during the late night and full power in the morning to extend the duration of the light in bad weather. Operating time / duration (please specify when ordering) You have the option from dawn to choose 4 consecutive time blocks with 1-15 hours duration and different light intensity of 10-100%. Example 1 - Night reduction with shutdown and morning light: From dusk 4 hours with 100%, then 2 hours with 50%, then 3 hours off (0%) and early in the morning 5 hours with 100% Example 2 - night shutdown: 4 hours 100%, 4 hours midnight 0%, 5 hours 100% Example 3 - 4 hours bright in the evening, then reduced to 50% for 4 hours, then 10 hours (rest of the night) to 50% In addition, the charge controller is equipped with a Smart Power function, which allows automatic dimming at night depending on the battery charge level. If the battery voltage drops below 50%, the lamp is automatically dimmed to 50%, this process is decreasing until the deep discharge protection starts. This setting enables safe operation even on the faint days in winter. The charge controller settings are preset by us according to customer requirements. If you want to change the settings, you need the remote control S-SOLS29. We will gladly help you to decide on the right presettings. All functions are preprogrammed by us free of charge, depending on the project and customer request, so that the luminaire is ready for use immediately after installation. Temperature-optimized battery charge and trickle charge to extend battery life. Overvoltage and deep discharge protection for battery. Reverse polarity and short circuit protection. Additional fuse Protection class: IP66 Warranty: 5 years Solar module specifications: Monocrystalline silicon with very high efficiency tempered protective glass, hailproof This high quality module technology also ensures charge in overcast skies. On dark days in winter, the recharging is limited, the light duration is thus reduced. Efficiency: > 19% Power: 120Wp (without extension) Life expectancy: approx. 25 years Performance Guarantee * 20 years 80% / 10 years 90% * except in the case of mechanical impact Battery storage: Battery Type: Lithium Ion LiFePo4 12V, maintenance-free, longlife, for solar cycle operation Lifetime approx. 10 years / 20 ° C Function even at low temperatures. For sufficient reliability in autumn or winter, we strongly recommend our extension sets. Self-sufficient operating time in overcast weather (with fully charged battery): a) Basic version: 4 days (44 hours) b) with extension set autumn: 5 days (60 hours) c) with extension set winter: 7 days (80 hours) The new emergency lighting function ensures the lighting even with low battery charge during very long periods of bad weather, but with reduced luminosity. The batteries are located in the mast and are protected from strong sunlight. Mast: Steel mast, hot-dip galvanized, Visible height: 5 m Ground piece: 80 cm for setting in concrete (on request also 6m - 8m height) For easier installation, we also offer installation sleeves into which the mast can be inserted. Lockable mast door for easy access to the controls. Delivery disassembled with the following components: LED lamp head with mast mounting, Solar battery Solar module with stable, screw-down mast mounting, Steel pole, Light control (already mounted in the mast). Illustrated assembly instructions in German or English. Other languages ​​on request. All components are pre-wired and prepared for quick setup.

Robust photovoltaic street light for cycle paths crossings and cycle overpasses. With wide-angle light emission. With LED lamp - no power connection required. High luminous intensity due to state-of-the-art SMD LED in combination with an electronic 12V-60V DC PWM driver. The brightness is comparable to an 80W mercury vapour lamp or 50W sodium vapour lamp. Very long, maintenance-free luminaire operation due to special design features. Intelligent microprocessor system control. Production and quality management in Germany. The solar light is maintenance-free - only the solar module should be cleaned with water occasionally. General technical data: Illuminated area: Approx. 8 x 16m Recommended street width: Max. 10 metres (for wider streets, a luminaire should be placed on both sides) Ambient temperature: -20°C ~ +50°C (extension -35°C ~ +65°C possible on request) Material: Brackets: Hot-dip galvanised steel (UV-resistant paint available at extra cost). Screws: VA stainless steel. Energy efficiency class: B Protection class: III safety extra-low voltage Marks of conformity: CE, RoHS, WEEE 20-year availability guarantee for spare parts. Luminaire head specification: Robust LED luminaire head made of die-cast aluminium LED lamp: SMD chipset Osram LED power: 30W Light colour: 4000K neutral white (on special order also 3000K warm white). No UV radiation for reduced insect attraction LED efficiency: > 135 lm/w Luminaire efficiency: > 130 lm/w Luminous flux lumen: 4000 lm Central illuminance: > 10 Lux (8m height) Average luminous intensity: > 6 Lux (8m) LED life: approx. 60,000 hours Protection class: IP65 (water and storm protected). Warranty: 5 years Luminaire control: Smart MPPT microprocessor control with wireless programming option. Readout of the current operating status with storage of the measurement data of all components of the last days. Automatic switch-on at sunset and switch-off at sunrise. (Switching level adjustable) Adjustable dimming during late night and full power again in the morning to extend the lighting duration in bad weather. Please specify desired lighting times and night-time dimming when ordering. You have the option of selecting 4 consecutive time blocks from dusk onwards, each lasting 1-15 hours and with varying light intensity from 10-100%. Example 1: From dusk 4 hours with 100%, then 2 hours with 50%, then 3 hours 30% and early in the morning 4 hours with 100%. Example 2: 4 hours at 100%, then 10 hours (rest of the night) at 50%. In addition, the charge controller is equipped with a Smart Power function that enables automatic dimming during the night, depending on the battery charge level. When the battery voltage drops below 50%, the lamp is automatically dimmed to 50%, this process is descending until the deep discharge protection kicks in. This setting enables safe operation even on the low-light days in winter. The charge controller settings are preset by us according to customer requirements. If you would like to change the settings, you will need the S-SOLS29 remote control. We will be happy to help you decide on the correct presettings. All functions are pre-programmed by us free of charge, depending on the project and customer requirements, so that the luminaire is ready for operation immediately after installation. Temperature-optimised battery charging and trickle charging to extend battery life. Overvoltage and deep discharge protection for battery. Reverse polarity and short circuit protection. Additional fuse Protection class: IP66 Warranty: 5 years Solar module specifications: Monocrystalline silicon with very high efficiency Tempered protective glass, hail-resistant. This high-quality module technology ensures charging even in overcast conditions. Efficiency: > 18% Output: 200Wp (without extension) Life expectancy: approx. 25 years Performance guarantee * 20 years 80% / 10 years 90% * except in the case of mechanical impact * except in case of mechanical impact Battery storage: Battery type: Lithium Ion LiFePo4 12V, maintenance-free, longlife, for solar cycle operation. Service life: approx. 10 years / 20°C Function even at low temperatures. On dark days in winter, recharging is limited and the lighting duration is thus shortened. For sufficient operating safety in autumn or winter, we strongly recommend our extension sets. Autonomous operating time in overcast weather (with fully charged battery): a) basic version: 4 days (44 hours) b) with extension set autumn: 5 days (60 hours) c) with extension set winter: 7 days (80 hours) The new emergency lighting function ensures lighting even when the battery charge is low during very long periods of bad weather, but with reduced luminosity. The batteries are located in the mast and are protected from strong sun heat. Mast: Steel mast, hot-dip galvanised, Visible height h1: 8m h2 Ground: 1000 mm Foundation depth: 130cm Mast top end Ø: 89mm d2 base Ø: 133 mm Wall thickness s: 3 mm For easier erection, we also offer installation sleeves into which the mast can be inserted. Lockable mast door, for easy access to the control unit. Supplied disassembled with the following components: LED lamp head with mast mounting, solar battery solar module with stable, screwable mast mounting, steel mast, luminaire control unit (already mounted in the mast). Illustrated assembly instructions in German or English. Other languages on request.

Robust photovoltaic street light with LED lamp. High luminous intensity thanks to state-of-the-art SMD LED in combination with an electronic 12V-60V DC PWM driver. The brightness is comparable to an 80W mercury vapor lamp or 50W sodium vapor lamp. Very long, maintenance-free luminaire operation due to special design features. Microprocessor Control, All brackets and fixings are hot-dip galvanized (with surcharge also with a coating as desired). The screws are made of VA stainless steel. Construction, production and quality management in Germany. General technical data: Illuminated area: approx. 25 x 10m Recommended mast spacing: approx. 25 meters Ambient temperature: -20° C ~ + 50° C (extension -35° C ~ + 65° C possible on request) Protection class: III Protective extra-low voltage Test mark: CE, RoHS, WEEE 20-year availability guarantee for replacement parts. Lamp specifications: LED Lamp: SMD Chipset Philips LED power: 30W Light colour 4000K pure white (on request also 3000K warm white or 6000K daylight). No uv-radiation for reduced insects attraction LED efficiacy: > 160 lm/w Lamp efficiacy: > 145 lm/w Luminous flux: > 5000 lm Central illumination: > 36 Lux (5m pole height) Average illumination: > 19 Lux (5m) Life time: 80000 hours Casing: Rigid aluminium die-cast. Seawater and thunderstorm-proof. Dimensions: 470mm x 230mm x 60mm Arm length: 300mm (on request, we supply with max. 2 meter arm) Protection degree: IP65 Guarantee: 5 years Light Control: Smart microprocessor control with infrared programming option. Reading the current operating status with storage of the measurement data of all components of the last days. Automatic switch on at sunset and switch off at sunrise. (Switching level adjustable) Adjustable dimming during the late night and full power in the morning to extend the duration of the light in bad weather. Operating time / duration (please specify when ordering) You have the option from dawn to choose 4 consecutive time blocks with 1-15 hours duration and different light intensity of 10-100%. Example 1 - Night reduction with shutdown and morning light: From dusk 4 hours with 100%, then 2 hours with 50%, then 3 hours off (0%) and early in the morning 5 hours with 100% Example 2 - night shutdown: 4 hours 100%, 4 hours midnight 0%, 5 hours 100% Example 3 - 4 hours bright in the evening, then reduced to 50% for 4 hours, then 10 hours (rest of the night) to 50% In addition, the charge controller is equipped with a Smart Power function, which allows automatic dimming at night depending on the battery charge level. If the battery voltage drops below 50%, the lamp is automatically dimmed to 50%, this process is decreasing until the deep discharge protection starts. This setting enables safe operation even on the faint days in winter. The charge controller settings are preset by us according to customer requirements. If you want to change the settings, you need the remote control S-SOLS29. We will gladly help you to decide on the right presettings. All functions are preprogrammed by us free of charge, depending on the project and customer request, so that the luminaire is ready for use immediately after installation. Temperature-optimized battery charge and trickle charge to extend battery life. Overvoltage and deep discharge protection for battery. Reverse polarity and short circuit protection. Additional fuse Protection class: IP66 Warranty: 5 years Solar module specifications: Monocrystalline silicon with very high efficiency tempered protective glass, hailproof This high quality module technology also ensures charge in overcast skies. On dark days in winter, the recharging is limited, the light duration is thus reduced. Efficiency: > 19% Power: 120Wp (without extension) Life expectancy: approx. 25 years Performance Guarantee * 20 years 80% / 10 years 90% * except in the case of mechanical impact Battery storage: Battery Type: Lithium Ion LiFePo4 12V, maintenance-free, longlife, for solar cycle operation Lifetime approx. 10 years / 20 ° C Function even at low temperatures. For sufficient reliability in autumn or winter, we strongly recommend our extension sets. Self-sufficient operating time in overcast weather (with fully charged battery): a) Basic version: 4 days (44 hours) b) with extension set autumn: 5 days (60 hours) c) with extension set winter: 7 days (80 hours) The new emergency lighting function ensures the lighting even with low battery charge during very long periods of bad weather, but with reduced luminosity. The batteries are located in the mast and are protected from strong sunlight. Mast: Steel mast, hot-dip galvanized, Visible height: 5 m Ground piece: 80 cm for setting in concrete (on request also 6m - 8m height) For easier installation, we also offer installation sleeves into which the mast can be inserted. Lockable mast door for easy access to the controls. Delivery disassembled with the following components: LED lamp head with mast mounting, Solar battery Solar module with stable, screw-down mast mounting, Steel pole, Light control (already mounted in the mast). Illustrated assembly instructions in German or English. Other languages ​​on request. All components are pre-wired and prepared for quick setup.

Very rigid photovoltaic street light with storing of electrical power for 10 days of lighting. Recommended for use in Northern Europe or russian countries with lower quantity of sunshiny days. High brightness corresponds to 120 watt mercury light. Very long maintenance-free system lifespan, by use of efficient LED lamps and electronic 24V-60V PWM driver. Microprocessor system control for lighting and charging. All components are surfaced with a grey, scratchproof 2-layers UV-resistant coating. The screws are made of stainless steel. This solar light is maintenance free - only the solar panel should be cleaned occasionally with water. Our systems are provided with serial numbers, wich can be validated to protect against malicious copies. General specifications: Lighted area:                          Aprx. 25 x 12m Distance from pole to pole:   25 - 30 meter Recommended pole height:  5m - 8m Ambient temperature:           -20°C ~ +55°C (extended temperature range -35°C ~ +65°C available on request) Max. direct sunshine temperature: 85° C / 176 F degree Protection class:                    III SELV Low safe voltage Approvals:                              CE, RoHS, WEEE 20 years sparepart supply ability. Lamp specifications: LED Lamp:                              SMD chipset Osram LED power:                             32W Light colour:                           4000K neutral white (on request 5000K cold white or 3000K warm white). No uv-radiation for reduced insects attraction LED efficiacy:                          > 160 lm/w Luminous flux:                       5000 Lm Central illumination:             > 22 Lux (at 6m pole height) Average brightness:             > 11 Lux (6m) Life time:                               Aprx. 80000 h Casing:                                   Rigid aluminium die-cast. Seawater and thunderstorm-proof. Protection degree:                IP66 5 years guarantee System controler specifications: Programmable Processor charge controler. MPPT maximum power point tracking for 30% better solar efficiency. Infra red remote control Metering memory for actual and last days system status. Automatic lamp start at sunset and turn-off by dawn. (Level adjustable) Smart dimming functions 10-100% to economize battery charging at snow, fog, rain or storm. Timer-dimmer:                     Full power at start-up, automatic dimming at midnight and full power again in the early morning. All functions are pre-programmed by us, for the project and to customer specifications, so that the lamp is ready for operation immediately after installation. Temperature feeded battery charging for extended battery life. Overcharge and deep-discharge protection for the battery. Reverse polarity and electronic short circuit protection. Additional electric fuse Protection degree :              IP66 5 years guarantee Solar panel specifications: High efficient monocrystalline silicone (tempered glass encapsulated, hailproof) This modern cell technology has a high degree of efficiency and allows charging also at cloudy weather. Efficiency:                              > 20% Power:                                   330Wp Life expectancy:                   aprx. 25 years 20 years 80% power guaranty * 10 years 90% power guaranty * * excepted is the complete failing (3 years guarantee) Battery specifications: Battery type:                        Lead gel 12V, On option Li-Ion LiFePo4 battery maintenance-free, longlife. For solar cycling charge operation Lifetime about 10 Years / 20°C. Functions well, even under low temperature. Autonomy at fully charged battery: 20 days at cloudy weather 120h (10 days) at absolutely no sunshine Battery box: The batteries are located underground for equalized temperature (longer life) and thieve protection. Rigid plastic box IP67 (non walkover) with cabel protection hose, steel reinforced: Size: L 496 x w 280 x h 270mm on option ABS plastic box IP66 (walk over): Size: L 550 x w 550 x h 480mm Including following components: LED light fixture with arm and pole mount bracket. Solar battery, Inground battery box, Solar module with frame and bracket for adjustable top-mount. System controler. Manual for easy mechanical and electrical setup in english language. Other languages on request. (Complete pre-wired unit without pole) Our systems will be configured to your demands and the local requirements. A product training and installation help is available. (Please ask for different versions for southern countries with many sunshiny days)
